Product Description
Use with any 1/2"Drive ratchet, bar or torque wrench.
Multiple functions: Angle setting, Torque setting, Unit setting, Mode setting, Data storage, Data clear, Data output & Online calibration.
Functions clockwise & anticlockwise.
Five button settings, twelve bright LED's (2 red & 10 green) and a large LCD visual screen.
Specifications: Torque Accuracy: CW +/- 3%.
Data Memory Size: 50 Readings.
Angle Accuracy: +/- 2¡(Rotating 90¡at speed of 30¡/ second).
Operating Range: 340Nm, 207.5Ft/Lb, 3009In/Lb, 3469Kg/Cm, 999¡.
Measured Angle / Torque Range: 17 to 340Nm, 125 to 250.7Ft/Lb, 150 to 3009In/Lb, 173 to 3469Kg/Cm, 1¡ to 360¡.
Pre-setting Number: 9 Sets. Operation Mode: Peak hold / Track.
Unit Selection: Nm, In/Lb, Ft/Lb, Kg/Cm, Degree of Angle.
Bright LED's: 12 LED (2 Red + 10 Green).
Battery: AAA x 2. Size: 85mm x 85mm x 60mm.
